TIM – Integrated Servo Motors
The TIM integrated servo motor is a cost effective and flexible solution, ideal for applications with limited control cabinet space and a decentral machine architecture. The TIM, with its high power density and compact size, enables space-saving machine designs and ultimately cabinet-less machines.
Product Highlights
- Frame size: 60 - 80 mm
- 0.64 to 2.55 Nm rated output torque
- 200W to 800W rated output power
- 3 digital inputs, 1 digital output
- Fieldbus: CANopen, EtherCAT
- Feedback: Absolute single turn,
- Absolute multi turn
- 24VDC / 48VDC bus voltage
- IP54 protection class (IP65 optional)
- Motor holding brake (optional)
- Integrated design minimizes component and wiring requirements
- Integrated Functional Safety - STO or optional Safe Motion Module (Cat 3, PL e)
- CE and cUL certifications
Downloads
Product Highlights
- Frame size: 60 - 80 mm
- 0.64 to 2.55 Nm rated output torque
- 200W to 800W rated output power
- 3 digital inputs, 1 digital output
- Fieldbus: CANopen, EtherCAT
- Feedback: Absolute single turn,
- Absolute multi turn
- 24VDC / 48VDC bus voltage
- IP54 protection class (IP65 optional)
- Motor holding brake (optional)
- Integrated design minimizes component and wiring requirements
- Integrated Functional Safety - STO or optional Safe Motion Module (Cat 3, PL e)
- CE and cUL certifications
Haaave you met
?
TIM is a compact integrated servo motor that eliminates control cabinets, cuts wiring, and frees valuable machine space. 48–60 VDC low-voltage power, Functional Safety-certified Safe Motion Module, and CANopen or EtherCAT connectivity come built in – so you install one unit and get drive, control, and safety in a single package.
Result: faster commissioning, lower total cost, and reliable performance in every decentralized machine.
Integrated Functional Safety-STO or optional Safe Motion Module (Cat 3, PL e)
Integrated servo
electronics
Flange size: 60, 80 mm
With/without brake
Feedback: absolute single turn/absolute multi turn
STO
I/O: 3 IN, 1 OUT
Fieldbus: EtharCAT, CANopen
Integrated Functional Safety-STO or optional Safe Motion Module (Cat 3, PL e)
Integrated servo electronics
Flange size: 60, 80 mm
With/without brake
Feedback: absolute single turn/absolute multi turn
STO
I/O: 3 IN, 1 OUT
Fieldbus: EtharCAT, CANopen
